SFP rau ethernet converter 1.25G DWDM 80km 50GHz
Kev piav qhia dav dav
Kev tso tawm kho qhov muag tuaj yeem ua tsis tiav los ntawm TTL qhov kev xav tau theem siab ntawm cov ntsiab lus ntawm Tx Disable, thiab lub kaw lus tseem tuaj yeem ua rau lub module ntawm I2C. Tx Txhaum yog muab los qhia tias kev cuam tshuam ntawm lub laser. Kev poob ntawm lub teeb liab (LOS) tso tawm yog muab los qhia txog qhov poob ntawm lub tswv yim optical teeb liab ntawm qhov tau txais lossis qhov txuas xwm txheej nrog tus khub. Lub kaw lus tseem tuaj yeem tau txais LOS LOS (lossis Txuas) / Cov ntaub ntawv xiam oob qhab / Nkag mus los ntawm I2C nkag nkag.
Qauv qauv | DWDM-SFP-1.25G-ZR | Lub Hom | HTF |
Encapsulation | SFP | Cov Ntaub Ntawv Ntsuas | 1250Mbs |
Wavelength | C17-C61 | Mus cuag | 80KM |
channel sib nrug | 50GHz | Sib cuam tshuam | Duplex LC |
Raws tu qauv | SFF-8472 MSA Ua Raws; MSA Raws | Cheebtsam kho qhov muag | DWDM EML laser transmitter APD thaij duab-kuaj |
Cable Hom | SMF （9 / 125µm） | DDM Pab Txhawb | Yog lawm |
Tx hwj chim | 0 ~ 4dBm | Rx Sens | & lt; -26dBm |
Ntau Yam Kub Kev Lag Luam （oC） | Kev ua lag luam: 0 ~ +70 Ncua Sijhawm: -10 ~ +80 Kev lag luam: -40 ~ +85 | Cov ntawv thov | SONET / SDH tes hauj lwm; Gigabit Ethernet; C Band DWDM tes hauj lwm; Fiber Channel |
Nta
● DWDM EML laser transmitter thiab tus lej PIN duab
● 50 GHz ITU channel spacing nrog kev sib dhos lub thawv yaug
● Cov Ntawv Kub Cov Nyiaj Tau SFP uas ntim tau yooj yim
Duplex LC / UPC hom pluggable optical interface
Ip Tsawg zog dissipation
En Hlau thaiv, rau EMI qis dua
● RoHS ua raws thiab coj tsis pub
Txhawb Digital Diagnostic Xyuas interface
● Ib qho +3.3V fais fab mov
Kev Tsis Paub Qhov Siab Ntau
Nws yuav tsum raug sau tseg tias kev ua haujlwm hauv kev dhau ntawm ib tus neeg tsis pub tshaj kev tshaj tawm yuav ua rau muaj kev puas tsuaj mus tas li rau qhov qauv no.
Tsis | Lub Cim | Min | Max | Chav Nyob | Sau ntawv |
Cia Khoom Kub | TS | -40 | 85 | oC | |
Kev khiav hauj lwm kub Cov Ntaub Ntawv | Tcov ntaub ntawv | Saib Cov Lus Qhia Yuam Kom Tau | oC | ||
Lub Hwj Chim Mov Voltage | VCC | -0.5 | 3.6 | V | |
Tus Kheej Txheeb Ze (tsis yog-hws) | RH | 5 | 95 | % | |
Puas Pov Tseg | THd | 5 | dBm |
Kev Xa Khoom, Xa Khoom thiab pabcuam
Warranty: 3 xyoo warranty
Kev pabcuam zoo tomqab muag
Cov qauv yog muaj rau kev xeem
Teb koj qhov kev nug hauv 24 teev
Koj tuaj yeem tau txais peb cov nyiaj them yug online ntawm 24 * 7
Loj muaj peev xwm ntawm kev tsim khoom thiab lub sijhawm xa khoom sai
Nrog pab neeg muaj txuj ci kev txhawb nqa
Customized label thiab pob, ODM thiab OEM kev pabcuam muaj
100% cov ntaub ntawv tshiab rau kev tsim khoom thiab 100% txhim khu kev qha zoo
Neeg kho tshuab qhov ntev
Cov FAQ
1 、 nqe lus nug ： Koj lub sijhawm khoom txhuas ua piv txwv yog dab tsi?
Teb ： Nws yog li ntawm 1-3 hnub ua haujlwm tom qab tau txais nyiaj.
2 、 nqe lus nug ： Koj qhov kev txiav txim kom tsawg kawg yog dab tsi?
Teb ： Kom ua tiav cov neeg siv khoom' zoo siab, peb txais qauv kev txiav txim, txawm tias ib qho.
3 、 nqe lus nug ： Hom cable dab tsi xav tau rau tus neeg hloov khoom no?
Teb ： The 1250Mb / s SFP DWDM 80km transceivers siv ib hom fiber ntau thaj cables nrog ob lub cav / txuas txuas nrog LC / UPC.
4 、 nqe lus nug ： Dab tsi yog qhov sib txawv ntawm MTP / MPO interface thiab LC interface 40G QSFP + transceivers?
Teb ： Ntawm ib sab tes, HTF 40G QSFP + transceivers nrog LC interface siv rau kev sib kis ntev dhau ntawm tib hom fiber ntau, thiab cov uas muaj MTP / MPO interface tau siv rau kev sib kis luv luv hla multimode fiber. Ntawm qhov tod tes, rau HTF 40G QSFP + transceivers nrog LC interface, lawv tsis tuaj yeem faib ua 4x10G thaum lawv siv 4 nthwv cua ntawm ib khub ntawm cov kabmob uas muaj ib hom thiab tsis kam qiv lawv tus kheej kom "cais" rau hauv 4 ua khub tsis muaj qhov tsis yooj yim rau kev sib cais ua lub nthwv dej. Txog rau HTF 40G QSFP + transceivers nrog MTP / MPO interface, lawv tuaj yeem siv rau hauv 4x10G kev sib txuas ntawm sab nraud 12-fiber mus tib seem rau 2-fiber duplex breakout cable, uas txuas nrog 40G transceiver rau plaub 10G optical interfaces.
