Ordering Information
| Khoom Code | Kev piav qhia |
| CFP2-400G-DCO-BD | 400GBPS COHERENT CFP2, DWDM C-BAND TUNABLE BiDi OPENZR + 200GBPS COHERENT CFP2, DWDM C-BAND TUNABLE BiDi METRO |
Ntsiab nta
| Tsev neeg khoom | CFP2-400G-DCO-BD |
| Form Factor | CFP2 |
| Host/Client Interface | |
| OTN | 1-2 OTU4; (OTL 4.4) |
| 1-2 OTUC1 | |
| Ethernet | 1 x 400GBASE-R; (1 x 400 GAUI-8) |
| 1 x 200GBASE-R; (1 x 100GAUI-4) | |
| 1 x 100GBASE-R; (1 x 100GAUI-2) | |
| 2 x 100GBASE-R; (2 x CAUI-4) | |
| 1 x 100GBASE-R; (1 x CAUI-4) | |
| Media Interface | |
| Tus txheej txheem txais | Intradyne Coherent Detection thiab qib siab txuas sib npaug |
| Ntau zaus | 191.275 - 196.125 THz, C-Band tunable, Flex-Grid |
| Lwm yam nta | |
| Hwm / Client Multiplexing (Ethernet cov neeg siv khoom) | Yog lawm |
| Lub party / Client Multiplexing (OTU4 cov neeg siv khoom) | Yog lawm |
| Spectral Shaping | Yog lawm |
| RMON | Yog lawm |
| MLG 2.0 & 3.0 pob tshab | Yog lawm |
| LLDP | Yog lawm |
| SyncE pob tshab | Yog lawm |
CFP2-400G-DCO-BD cov khoom sib txawv txhawb nqa cov kev sib txuas hauv qab no ntawm Network framing thiab kev hloov kho
hom raws li qhia hauv qab Table
| Payload tus nqi | Kab hom | Symbol Baud Rate (+/{1}}ppm) |
Modulation | FEC | Net Coding Tau Txais (NCG) (dB) |
Ua ntej FEC BER |
| 400G | 400G-400ZR-OFEC-16QAM | 60 138 546 798 | DP-16QAM | OFEC | 11.6 | 2.00E-02 |
| 200G | 200G-FOIC2-OFEC-QPSK | 63 139 467 923 | DP-QPSK | |||
| 200G-200ZR-OFEC-QPSK | 200G-200ZR-OFEC-QPSK | 60 138 546 798 | ||||
| 200G-FOIC2-OFEC-16QAM | 200G-FOIC2-OFEC-16QAM | 31 569 733 961 | DP-16QAM | |||
| 100G | FOIC1-OFEC-DP-DQPSK | 31 569 733 961 | DP-DQPSK | |||
| 100G-100ZR-OFEC-QPSK | 100G-100ZR-OFEC-QPSK | 30 069 273 399 |
Cim npe nrov: cfp2 400g dco bidi digital coherent module, Tuam Tshoj, tuam ntxhab, lwm tus muag khoom, Hoobkas, kho, yuav, nqe, bulk, tshaj hom
