Qhov no 8 Txoj hlua khawm hluav taws xob tau siv rau kev sib txuas ncaj qha los ntawm QSFP + rau (4) SFP + cov chaw nres nkoj uas tsis muaj qhov ntxaij lossis qhov nruab nrab hauv nruab nrab. Qhov LSZH cable no tau tsim thiab sim coj los ua raws li IEC-60332-1 thiab IEC-61034.
Cov Lus Qhia Tshwj Xeeb
Cov tsis | Chav Nyob | Muaj nuj nqis |
Fiber ntau hom | - | OM4 (OM3) 50 / 125μm |
MTP Sib Txuas IL | dB | 0.35dB Max (0.15dB Ntaus.) |
MTP Txuas RL | dB | 20dB |
Attenuation ntawm 850nm | dB / km | 2.3 |
Tsho OD | hli | 3.0 |
Teeb Tensile Ntsaws | N | 100 |
Cable Tsho | - | LSZH |
Kev khiav hauj lwm kub | ° C | -10 ~ +70 |
Wavelength | nm | 850/1300 |
LC Txuas IL | dB | 0.2dB |
LC Connector RL | dB | 20 |
Attenuation ntawm 1300nm | dB / km | ≤0.6 |
Ntxuam-Hauv Qhov taub | hli | 2.0 |
Lub Sij Hawm Ntev Tensile Load | N | 50. |
Fiber ntau suav | 8 Cov Pob Khoom | |
Cia Khoom Kub | ℃ | -40 ~ +85 |
Muaj cov khoom siv zoo tshaj plaws rau kev tiv thaiv ib puag ncig
Kev siv hluav taws xob ntau tshaj plaws hluav taws xob cable, tiv taus kub kub, hluav taws kub nyhiab thaum lub sijhawm sib tsoo muaj lub luag haujlwm tiv thaiv ib puag ncig.
Hmoov av tsim qauv
Kev tsim kaw ntawm lub plua plav tuaj yeem tiv thaiv cov kab hluav taws xob txuas ua ke los ntawm kev ua qias tuaj thiab kev puas tsuaj, thiab ua kom lub cev sib txuas ntawm cov cim xaib.
Txhawb 40G / 100G network txuas nrog qhov siab tuab thiab raug. Txuag cov chaw siv hluav taws xob thiab txhim kho kev sib koom tes.
TRANSMIT DATA NROG YOOJ YIM
Tsim kom muaj cov ntaub ntawv nrawm sib txuas hauv cheeb tsam thaj chaw hauv koj cheeb tsam siv MTP rau 8x LC 40GB 50/125 OM3 Fiber Optic Cable. Qhov no breakout-style multimode fiber ntau optic cable tuaj yeem siv rau hauv thaj chaw plenum thiab yog qhov tsim nyog rau cov ntaub ua haujlwm siab thiab cov ntaub ntawv fiber ntau faib cov tshuab.
MTP / MPO THIAB LC YEEM COV LUS RAU TUS KHEEJ NCEEM
Rau kev teeb tsa kom nrawm, MTP rau LC 40GB 50/125 OM3 Fiber Optic Cable muaj qhov tshwj xeeb MTP / MPO multimode txiv neej txuas thiab yim LC multimode txiv neej txuas, tshem tawm qhov xav tau ntawm splicing. Haum rau kev siv nrog cov transceivers xws li SFP, SFP + thiab XFP, LC cov khoom sib txuas txuag thaj chaw kom haum rau ntau cov kab hluav taws xob.
MULTIMODE FIBER RAU COV KEV THOV KEV PAB CUAM BACKBONE
Lub tswv yim zoo raws li ib feem ntawm caj qaum, lub kab hlau txuas no siv multimode optical fiber. Multimode optical fibers muaj qhov loj dua thiab loj dua cov teeb pom kev muaj peev xwm ntau dua li cov hom fiber ntau thiab tau zoo dua rau kev xa cov ntaub ntawv hla qhov chaw nyob deb, xws li nyob hauv ib qho chaw ua haujlwm.
Cov FAQ
Q1: MOQ Kev Txiav Txim Siab?
A1: Daim Adapter, thaj lav, cov khoom sib txuas thiab lwm yam ... MOQ yog 1 pcs. Peb muaj ntau tshaj 10 xyoo kev ua haujlwm nyob hauv daim teb no, peb tuaj yeem tsim kho kom haum rau koj cov kev xav tau.
Q2: Koj qhov qauv coj ua piv txwv yog dab tsi?
A2: Peb tuaj yeem muab cov qauv dawb rau koj rau optics muaj fiber ntau, tab sis cov neeg siv khoom yuav tsum them nqi courier.
Q3: Koj puas tuaj yeem ua OEM?
A3: Qhov tseeb.
